    QUADRANT STRAIN CLAMPS
    Loading file
    • Fullscreen
    • Wireframe
    • Zoom In
    • Zoom Out
    • Rotation
    • Screenshot
    • Help

    Controls

    ×
    • Rotate with the left mouse button.
    • Zoom with the scroll button.
    • Adjust camera position with the right mouse button.
    • Double-click to enter the fullscreen mode.
    • On mobile devices swipe to rotate.
    • On mobile devices pinch two fingers together or apart to adjust zoom.
    • On mobile devices 3 finger horizontal swipe performs panning.
    PRODUCT NO.
    ETQSC-552-N
    Get The Latest Quotes
    Application:

    The clamp is suitable for fixing and tightening the overhead insulated conductor on the end of the overhead insulated conductor.

    Features:

    Additional information

    Material:

    Clamp body and keeper are ductile iron, grade 654512.
    Clevis pins, u-bolts, nuts and washers are steel.
    Socket and clevis fittings are ductile iron, grade 654512.
    Cotter pins are stainless steel.
    Finish:

    All parts, except cotter pins, hot dip galvanized per ASTM A-153.
    Ultimate Strength:

    20000 lbs
    Packing:

    Carton&Plywood Pallet&Crate
    SUSPENSION CLAMPS
    SUSPENSION CLAMPS
    Material:

    Clamp body and keeper are Aluminum alloy.
    Clevis pins, u-bolts, nuts and washers are steel.
    Cotter keys are stainless steel.
    Ultimate Strength:

    25000lbs
    Packing:

    Carton&Plywood Pallet/Crate
    OVAL EYE NUT
    OVAL EYE NUT
    &nbsp

    Eyenuts are tapped to fit hot dip galvanized bolts made to ANSI specifications
    Designed to develop strength ratings consistent with the bolts with which they are used – i.e. 1/2" = 85000 lbs, 5/8" = 13,550 lbs, 3/4" =20,050 lbs
    Material:

    Steel/Ductile iron grade 654512.
    Finish:

    All parts, except cotter pins, hot-dip galvanized per ASTM A-153.
    Packing:

    Carton&Plywood Pallet/Crate
    DOUBLE CLEVIS LINK
    DOUBLE CLEVIS LINK
    Material

    STEEL
    Finish

    Hot Dip Galvanized per ASTM A-153
    Ultimate Strength

    30,000 lbs
    Packing

    Carton&Plywood Pallet/Crate
