Pole Line Hardware

SUSPENSION TRUNNION  CLAMPS
Material:

Body & Keeper are Ductile iron
Hardwares are Steel

Finish:

All parts are hot dip galvanized per ASTM A-153

Diameter Range:

0.25''-1.26''

Packing:

Carton&Plywood Pallet/Crate

POLE EYE PLATE
Material:

Ductile iron

Finish:

Hot Dip Galvanized per ASTM A-153

Strength Rating:

20,000 lbs. at 45 and 90 degrees

Packing:

Carton&Plywood Pallet/Crate

POLE EYE PLATE
Material:

Ductile iron

Finish:

Hot Dip Galvanized per ASTM A-153

Strength Rating:

20,000 lbs. at 45 and 90 degrees

Packing:

Carton&Plywood Pallet/Crate

POLE TOP INSULATOR BRACKET
Material:

Ductile iron

Finish:

Hot Dip Galvanized per ASTM A-153

Min Ultimate Bending Moment at Base:

30000 in-lbs

Packing:

Carton&Plywood Pallet/Crate

THIMBLE EYE NUT-TRIPLE EYE
Bolt Diameter:

5/8"/3/4"

Strength Ratings:

23000 lbs

Material:

Ductile iron

Finish:

Hot Dip Galvanized per ASTM A-153

Packing:

Carton&Plywood Pallet/Crate

THIMBLE EYE NUT-TWIN EYE
Bolt Diameter:

5/8"/3/4"

Strength Ratings:

23000 lbs

Material:

Ductile iron

Finish:

Hot Dip Galvanized per ASTM A-153

Packing:

Carton&Plywood Pallet/Crate

THIMBLE CLEVIS
Material:

Ductile iron

Finish:

Hot Dip Galvanized per ASTM A-153

Packing:

Carton&Plywood Pallet/Crate

HOOK GUY ATTAHMENTS
Material:

Ductile iron

Finish:

Hot Dip Galvanized per ASTM A-153

Strength Rating:

15000lbs

Packing:

Carton&Plywood Pallet/Crate

BALL CLEVIS-30
Material:

Body and Hardware: Steel
Pin: Stainless Steel

Finish:

Hot Dip Galvanized per ASTM A-153

Packing:

Carton & Plywood Pallet & Crate
