TRIPLE STRAD NO WRENCH SCREW ANCHOR
3D
2D
PRODUCT NO.
ET25TSNWSA-BT01
200 in stock
Application:
The No-Wrench Anchor can be placed with power equipment or by hand. No-Wrench Anchors are made of a forged eye anchor rod with a welded helix and angle cut tip. All No-Wrench Anchors have 3 guy attachments.
SPECIFICATION
| CatalogNumber | MacLean | Hubbell | Helix DiameterInches (cm) | Rod DiameterInches (cm) | Rod LengthInches (cm) | WeightLbs (kg) |
| TT-6524 | J6524WCA | 4335 | 4 (10.2) | 3/4 (1.9) | 54(137.2) | 8.1 (3.7) |
| TT-6526 | J6526WCA | 6346 | 6 (15.2) | 3/4 (1.9) | 66(167.6) | 10.9 (4.9) |
| TT-6528 | J6528WCA | PS816 | 8 (20.3) | 1 (2.5) | 66(167.6) | 19.1 (8.7) |
| TT-6530 | J6530WCA | 10146 | 10 (25.4) | 1-1/4(3.2) | 66(167.6) | 30.3(13.7) |
| TT-6550 | J6550WCA | 10148 | 10 (25.4) | 1-1/4(3.2) | 96(243.8) | 41.1(18.6) |
Features:
Additional information
| Material: | STEEL |
|---|---|
| Finish: | Hot Dip Galvanized per ASTM A-153 |
| Packing: | Steel Pallet |
