    POLE EYE PLATE
    Loading file
    • Fullscreen
    • Wireframe
    • Zoom In
    • Zoom Out
    • Rotation
    • Screenshot
    • Help

    Controls

    ×
    • Rotate with the left mouse button.
    • Zoom with the scroll button.
    • Adjust camera position with the right mouse button.
    • Double-click to enter the fullscreen mode.
    • On mobile devices swipe to rotate.
    • On mobile devices pinch two fingers together or apart to adjust zoom.
    • On mobile devices 3 finger horizontal swipe performs panning.
    PRODUCT NO.
    WL23PEP538C-LT01
    Get The Latest Quotes
    Application:

    Cast ductile iron pole eye plate for attaching to fiberglass guy strains or clevis fittings is rated for 20,000 lbs. at 45 and 90 degrees.

    Common industry slang is Monkey Face.

    Features:

    Additional information

    Material:

    Ductile iron
    Finish:

    Hot Dip Galvanized per ASTM A-153
    Strength Rating:

    20,000 lbs. at 45 and 90 degrees
    Packing:

    Carton&Plywood Pallet/Crate
    OVAL EYE NUT
    OVAL EYE NUT
    &nbsp

    Eyenuts are tapped to fit hot dip galvanized bolts made to ANSI specifications
    Designed to develop strength ratings consistent with the bolts with which they are used – i.e. 1/2" = 85000 lbs, 5/8" = 13,550 lbs, 3/4" =20,050 lbs
    Material:

    Steel/Ductile iron grade 654512.
    Finish:

    All parts, except cotter pins, hot-dip galvanized per ASTM A-153.
    Packing:

    Carton&Plywood Pallet/Crate
    THIMBLE EYE NUT-TWIN EYE
    THIMBLE EYE NUT-TWIN EYE
    Bolt Diameter:

    1”
    Strength Ratings:

    36000 lbs
    Material:

    Steel
    Finish:

    Hot Dip Galvanized per ASTM A-153
    Packing:

    Carton&Plywood Pallet/Crate
    CABLE VIBRATION DAMPER
    CABLE VIBRATION DAMPER
    Clamp Material:

    Aluminium Alloy
    Hammer Head Material:

    Grey Cast Iron,Painted
    Weight(kg):

    2.2-12.9
    Span:

    100m,150m,200m,300m,400m
    Packing:

    Carton & Plywood Pallet/Crate
