    POLE EYE PLATE
    Loading file
    • Fullscreen
    • Wireframe
    • Zoom In
    • Zoom Out
    • Rotation
    • Screenshot
    • Help

    Controls

    ×
    • Rotate with the left mouse button.
    • Zoom with the scroll button.
    • Adjust camera position with the right mouse button.
    • Double-click to enter the fullscreen mode.
    • On mobile devices swipe to rotate.
    • On mobile devices pinch two fingers together or apart to adjust zoom.
    • On mobile devices 3 finger horizontal swipe performs panning.
    PRODUCT NO.
    WL23PEP800C-LT01
    Get The Latest Quotes
    Application:

    Cast ductile iron pole eye plate for attaching to fiberglass guy strains or clevis fittings is rated for 20,000 lbs. at 45 and 90 degrees.

    Common industry slang is Monkey Face.

    Features:

    Additional information

    Material:

    Ductile iron
    Finish:

    Hot Dip Galvanized per ASTM A-153
    Strength Rating:

    20,000 lbs. at 45 and 90 degrees
    Packing:

    Carton&Plywood Pallet/Crate
    BALL CLEVIS
    BALL CLEVIS
    Material:

    Forged steel.
    Clevis pins, bent clevis bolts and nuts are steel.
    Cotter pins are stainless steel.
    Finish:

    All parts, except cotter pins, hot dip galvanized per ASTM A-153.
    ANSI Class: 52-3 & 5
    Ultimate Strength:

    30000lbs
    Packing:

    Carton&Plywood Pallet/Crate
    DOUBLE CLEVIS LINK
    DOUBLE CLEVIS LINK
    Material

    STEEL
    Finish

    Hot Dip Galvanized per ASTM A-153
    Ultimate Strength

    30,000 lbs
    Packing

    Carton&Plywood Pallet/Crate
    STRAIGHT-LINE DEAD END CLAMPS
    STRAIGHT-LINE DEAD END CLAMPS
    Material:

    Clamp body and keeper are ductile iron, grade 654512.
    Clevis pins, u-bolts, nuts and washers are steel.
    Socket and clevis fittings are ductile iron, grade 654512.
    Cotter pins are stainless steel.
    Finish:

    All parts, except cotter pins, hot-dip galvanized per ASTM A-153.
    Ultimate Strength:

    5000 lbs
    Packing:

    Carton&Plywood Pallet&Crate
