    PRODUCT NO.
    ET24PBC-BT02
    Get The Latest Quotes
    Application:

    Pole band clamp is an accessory that is used for attaching secondary racks to the poles. The secondary racks are then used for supporting other pole line fittings and even the cables. A pole band clamp is also known as the pole fastener or a fastening clamp.

    Features:

    Additional information

    Material:

    STEEL
    Finish:

    Hot Dip Galvanized per ASTM A-153
    Packing:

    Carton&Plywood Pallet/Crate
    ANCHOR SHACKLE
    ANCHOR SHACKLE
    Material:

    Forged steel.
    Clevis pins and clevis bolts are high strength steel.
    Cotter pins are stainless steel.
    Finish:

    All parts, except cotter pins, hot dip galvanized per ASTM A-153.
    Ultimate Strength:

    25000 lbs
    Packing:

    Carton&Plywood Pallet/Crate
    DOUBLE CLEVIS LINK
    DOUBLE CLEVIS LINK
    Material

    STEEL
    Finish

    Hot Dip Galvanized per ASTM A-153
    Ultimate Strength

    30,000 lbs
    Packing

    Carton&Plywood Pallet/Crate
    THIMBLE EYENUT
    THIMBLE EYENUT
    Bolt Diameter:

    5/8"/3/4"
    Maximum Strand:

    1/2"
    Strength Ratings:

    23000 lbs
    Material:

    Ductile iron, grade 654512.
    Finish:

    Hot Dip Galvanized per ASTM A-153
    Packing:

    Carton&Plywood Pallet/Crate
