    COMBINATION GUY ATTACHMENTS
    Loading file
    • Fullscreen
    • Wireframe
    • Zoom In
    • Zoom Out
    • Rotation
    • Screenshot
    • Help

    Controls

    ×
    • Rotate with the left mouse button.
    • Zoom with the scroll button.
    • Adjust camera position with the right mouse button.
    • Double-click to enter the fullscreen mode.
    • On mobile devices swipe to rotate.
    • On mobile devices pinch two fingers together or apart to adjust zoom.
    • On mobile devices 3 finger horizontal swipe performs panning.
    PRODUCT NO.
    ETCGA-358-3
    Get The Latest Quotes
    Application:

    A versatile guy attachment for light to medium loading.

    Can be used with strand or fiberglass strain insulator. Designed for use on round or flat surfaces.

    Features:

    Additional information

    Material:

    Ductile iron, grade 654512
    Finish:

    Hot Dip Galvanized per ASTM A-153
    Maximum Strand Diameter:

    3/8"
    Strength Rating:

    15000lbs
    Packing:

    Carton&Plywood Pallet/Crate
    DOUBLE CLEVIS LINK
    DOUBLE CLEVIS LINK
    Material

    STEEL
    Finish

    Hot Dip Galvanized per ASTM A-153
    Ultimate Strength

    30,000 lbs
    Packing

    Carton&Plywood Pallet/Crate
    QUADRANT STRAIN CLAMPS
    QUADRANT STRAIN CLAMPS
    Material:

    Clamp body and keeper are ductile iron, grade 654512.
    Clevis pins, u-bolts, nuts and washers are steel.
    Socket and clevis fittings are ductile iron, grade 654512.
    Cotter pins are stainless steel.
    Finish:

    All parts, except cotter pins, hot dip galvanized per ASTM A-153.
    Ultimate Strength:

    20000 lbs
    Packing:

    Carton&Plywood Pallet&Crate
    THIMBLE EYENUT
    THIMBLE EYENUT
    Bolt Diameter:

    5/8"/3/4"
    Maximum Strand:

    1/2"
    Strength Ratings:

    23000 lbs
    Material:

    Ductile iron, grade 654512.
    Finish:

    Hot Dip Galvanized per ASTM A-153
    Packing:

    Carton&Plywood Pallet/Crate
