    8-WAY EXPANDING ANCHOR
    Loading file
    • Fullscreen
    • Wireframe
    • Zoom In
    • Zoom Out
    • Rotation
    • Screenshot
    • Help

    Controls

    ×
    • Rotate with the left mouse button.
    • Zoom with the scroll button.
    • Adjust camera position with the right mouse button.
    • Double-click to enter the fullscreen mode.
    • On mobile devices swipe to rotate.
    • On mobile devices pinch two fingers together or apart to adjust zoom.
    • On mobile devices 3 finger horizontal swipe performs panning.
    PRODUCT NO.
    ET248WEA-BT01
    Get The Latest Quotes
    Application:

    Expanding anchors are a key component in a number of different industries, particularly in telecommunications. These anchors make use of the soil around them — typically rocky or hard soil for these products — to help create anchor points and provide stability for structures, cables, and equipment.

    Features:

    Additional information

    Hole Size:

    8"
    Area Square:

    135"
    Weight(kg):

    7.3 LBS
    Finish:

    Coated with a rust inhibitor or HDG
    Packing:

    Carton & Plywood Pallet/Crate
    THIMBLE EYENUT
    THIMBLE EYENUT
    Bolt Diameter:

    5/8"/3/4"
    Maximum Strand:

    1/2"
    Strength Ratings:

    23000 lbs
    Material:

    Ductile iron, grade 654512.
    Finish:

    Hot Dip Galvanized per ASTM A-153
    Packing:

    Carton&Plywood Pallet/Crate
    OVAL EYE NUT
    OVAL EYE NUT
    &nbsp

    Eyenuts are tapped to fit hot dip galvanized bolts made to ANSI specifications
    Designed to develop strength ratings consistent with the bolts with which they are used – i.e. 1/2" = 85000 lbs, 5/8" = 13,550 lbs, 3/4" =20,050 lbs
    Material:

    Steel/Ductile iron grade 654512.
    Finish:

    All parts, except cotter pins, hot-dip galvanized per ASTM A-153.
    Packing:

    Carton&Plywood Pallet/Crate
    SUSPENSION CLAMPS
    SUSPENSION CLAMPS
    Material:

    Clamp body and keeper are Aluminum alloy.
    Clevis pins, u-bolts, nuts and washers are steel.
    Cotter keys are stainless steel.
    Ultimate Strength:

    25000lbs
    Packing:

    Carton&Plywood Pallet/Crate
